Modern locomotive engineering, with questions and answers .. (1913)
Swingle, Calvin Franklin, 1846- [from old catalog] · Chicago, F. J. Drake & co · leaf 87
8o LOCOMOTIVE ENGINEERING … Figure 30 burn cheaper grades of coal than was possible with theolder type of boiler. It may be used (with somemodifications) for both soft and hard coal. Fig. 29 shows a sectional eleva-tion of a modern locomotiveboiler, and Fig. 30 an end viewof one-half of the flue sheet andone-half of the back…
Locomotives
