Modern mechanism, exhibiting the latest progress in machines, motors, and the transmission of power, being a supplementary volume to Appletons' cyclopaedia of applied mechanics (1892)
Benjamin, Park, 1849-1922 · New York, D. Appleton · leaf 134
Fio. 6.—Frietional belt-gearing. Fig. 7.—Almonds right-angled coupling. ing-drum, such as is used in pile-drivers and like hoisting machinery. The sectional viewshows its use as a cut-off coupling. The rim of the clutch, as shown, contains a groove withinternal beveled surfaces, each of which is…
Mechanical engineering
