ixed on the foundation. The Great Steel Derrick at the Brooklyn (N. Y.) Navy-Yard is carried on a pontoon 60 ft.wide by 63 ft. long. The tower is built of steel I-beams and rods, and contains 63 tons of metal. 156 CRANES. The king post is 65 ft. high ; 14 ft. 7 in. from its base it passes through… … Km. 1.—Sellers .Mt-ntw s\viii;:iiig crane. members of tlic front boom are 16A in. I-beams, spaced far enough apart for tlie stieaves andtackle to work between. The object of the back boom is simply to aflFord a point of attach-ment with advantageous leverage for the back-stays. The upper surface of…
