dynamo at I) pours its current into the cir-cuit, leaving the commutatf)r by the upper brush, whence it ftows through the field-magnetsFJl,iiud round the circuit oflamps 7^ L, back to the negative terminals. Suppose, now.some of the lamps to be extinguished by switches which short-circuit them; the… … FiG. 21—Compounddynamo.
