the field-raagnets are made very heavy, so as to maintain anextreraelv intense field with comparatively little expenditure of current-energy, and the poleprojections on the armature being almost directly in contact with the pole-pieces, concentratethe lines of force of the fielddirectly upon the… … Fig. 54.—Weston armature.
