at such valves have littletendency to wear leaky, and. moreover, any slight leak that may develop is easily repaired byhand-grinding. Fig. l is a sectional view of an air-cylinder with the gear applied. Theprinciple of this gear is very simple. The usual form of valve chatters because the air 16… … Fig. 1.—Rand compressor.
