ide of which is fastened a coil, t^irough which thewater is forced—a circulating pump being especially provided for this purpose. The waterenters the coil at D, and is converted into steam while traversing the pipes FF, and Anallythe mingled steam and water passes back to the boiler at ^. The coil… … FiG. 9.—Button steam flre-eugine. 264 ENGINES, FIRE, STEAM. placed in a few hours. The water, in entering at D, is separated into two parts, and theninto four parts, by a patent device inserted in the dividers at the bottom, so that each sectiongets its equal amount of water in proportion to the…
