rew is 7 ft. 9 in. diameter by 12 ft. * In test No. 8 water was drafted 2? ft. and forced ui> an elevation. ENGINES, FIRE, STEAM. 267 pitch. Back of this comes the Kunstadter swiveling-screw and gear. This is connected by auniversal joint to the shaft, which joint comes in line with the axis of… … i- iii. IJ.—Fire-boat Nt-w-VorRer. the condenser are provided. The condenser is of the tubular pattern, with about 2.000 sq. ft.of condensing surface. Steam-steering gear and engine are provided in addition to theregular hand-steering apparatus. For signaling, a steam-chime whistle and a steam…
