Modern mechanism, exhibiting the latest progress in machines, motors, and the transmission of power, being a supplementary volume to Appletons' cyclopaedia of applied mechanics (1892)
Benjamin, Park, 1849-1922 · New York, D. Appleton · leaf 296
Fio. ].—Pearsalls hj-draulic engine. ENGINES, HYDEAULIC. 275 … Fig. 2.- Pearsalls hj-draulic engine. Indicator—diagrams.Hydraulic Rams.—The followint^ descriptions of experimental hydraulic rams are takenfrom a paper by John Richards, of San Francisco {Proc. Inst. 31ech. Engrs., Feb., 1888): Fig. ^ ^ ^ 3 represents a small ram having an inlet-pipe / of from 3…
