ythe Watts-Campbell Co., of Newark. N. .1. The engines are tandem-compound, coupledto the shaft at right angles. The hij,di-pressure cylinders are 20 in. diameter and the low-pressurr- ;{(• in.; stroke of pistons, 4S in. The engines run at a speed of ()4 revolutions permin. H(»lh the hiKJi and low… … 324 EXGIXES, STEAM, STATIONARY RECIPROCATING. The exhaust from tlie high-pressure cylinder passes down through the legs to the receiver,which is cast as part of the low-pressure cvliiuler and includes the jacket-space of that cyl-inder. From the low-pressure cylinder tlie exhaust goes through a…
