by the movement of the swinging pail, asindicated by the dotted lines. Fig. 7 shows— Tlie Shaw ContruUing and Shut-off Suzzle (in section), by means of which a stream canbe reduced to any size or shut off at will. A conical plug, operated by an exterior hand-wheel, is inserted more or less into the… … Fig. 8.—Clemens spray nozzle Fig. 9.—Oyston spray-nozzle.
