Modern mechanism, exhibiting the latest progress in machines, motors, and the transmission of power, being a supplementary volume to Appletons' cyclopaedia of applied mechanics (1892)
Benjamin, Park, 1849-1922 · New York, D. Appleton · leaf 416
l-io. .).—Tlif Ilalti Wliilni-v rack-cultiii;i iiiacliiin GEAR-CUTTING MACHINES. 395 Swaseys Process for Generating and Cutting Spur-Gears.—A new process for generation;and cutting the teeth of spur-wheels is thus described by Ambrose Swasey, of the firm ofWarner & Swasey, Cleveland, O. {Trans.… … instead of making all gears so that they wdl run into a rack, the rack is transformed into acutj^ing-tool, and by it the teeth of wheels of any diameter are generated and cut at the sametime. Pig. G illustrates a gear generating and cutting engine constructed on this principle.The cutters are shown…
