Fig. 9.—Knife-grinder. The Tanite Aufomaiic Planer Knife-Grinder is shown in Fig. 9. In this machine theknife is ground with a straight bevel with no change until the wheel is worn out, or it can bemodified to grind a concave bevel, or square edges. … Car brnss-f;rii)(ler. The Tnnite Car Brnn/^-Grinder is shown in Fig. 10. The brass is clamped between thejaws of the chuck l)y a cam-motion actuated l)y a handle. Tlie chuck fits into planed guides,and thus travels sipiare with the mulion of the wheel. The talile is moved liuri/.outaliy l)ythe…
