Fio. 3.—Dead-stroke ijower-hammer. Kiu. 4.—Dead-slnike ijower-hainmer. the throw of tlie ram, while at the same time the stroke of the eccentric is shortened. Thehammer is operated by an eccentric at the rear, connected by a pitman to the saddle or oscil-lator which carries the helve, and by this…
