Fig. 30.—The Holmes binder complete. i;;<ias>:?i:.fr Woods sheaf-carrier. Pig. 31 shows the manner in which the sheaf-carrier folds backward,wing-like, to deposit its load. The operator can thus group his sheaves in such a manner as … Fig. .11.—Sheaf-carrier unloading. to greatly reduce the labor of stocking. Fig. 32 shows this binder with the back half of thetable omitted. The packers and ejectors arc in pairs. The pair of parallel bars in the table areadjustaljle higher or lower to determine the size of gavel. The automatic…
