upon the ricker-head, a horse passing on eitherside, and the teeth of the sweep passing between the ricker-teeth and transferring the load to them. The horse attachedto the hoist of the ricker, by means of a power-drum and pul-leys, swings the ricker-head aloft on two long-hinged arms,which,… … FiG. 8.—Sling-pulley.
