Modern mechanism, exhibiting the latest progress in machines, motors, and the transmission of power, being a supplementary volume to Appletons' cyclopaedia of applied mechanics (1892)
Benjamin, Park, 1849-1922 · New York, D. Appleton · leaf 463
Fig. 1.—Hay-loader. … Fig. 1 Fig. 2. Fig. 3. Figs. 1-3.—Hay-rake. which hold them in place, and rebolting them united midway of the hounds. An extra single-tree and a false pole-lip are .supplied. Thus the rake is rendered available for either onehorse or a span, and in an emergency the mower-team may be shifted to the…
Mechanical engineering
Internet Archive · Boston Library Consortium · Public Domain Mark 1.0. Free to use for anything.
