ides on three wheels,the rear one a caster, giving triangular support and maintaining the operating axis parallel HEATERS, FEED-WATER. 443 with the surface of the ground at suitable height. One of the two forward wheels is connectedby a chain-drive with a cross-shaft geared by cogs to an oblique… … Fig. 4.—Side-delivery hay-rake. about 45^ from the line of travel, the tedders successively rake and pitch the swath-hay towardand finally beyond one side of the machine, continuously, into a loose, well-ventilated wind-row, without rolling or compressing it. A strip some 10 ft. wide is windrowed…
