Fig. 12.—Gap chucking-lathe. being 20f in. long. The cone is balanced, and has four shifts for a wide belt. The head-stockhas ground journals with anti-friction metal boxes, which compensate for wear and preservethe original alignment of the live and dead centers. The bed-slider is operated by rack… … Fig. 13.—Pulley-lathe. and work of a similar character. Power is transmitted to the spindle through tangent gear-ing. The pulleys, being first bored, are placed on a mandrel and are driven by an equalizingdriver, distributing the strain evenly on the arms. The tool-slides are mounted upon…
