tom. The gainingof the staves, 1 in. deep,is done by hand, leav-ing a chine of 6 in. be-low the bottom. In alltanks the staves standperpendicular to thebottoms. The bottompieces, 3 to 4 in. thick,are cut to a diameter of2 in. greater than thatof the finished tank;they are grooved andjoined by a… … Fia. 6 —Leaching-vat—vertical section placed on a solid foundation, should be sufficiently high to allow access to the bottom in caseof leakage. The bottoms rest on joists 3 to 4 in. wide and 10 to 12 in. deep, placed about 2 ft.G in. apart, so that the staves are left entirely free. Hoops are made…
