Modern mechanism, exhibiting the latest progress in machines, motors, and the transmission of power, being a supplementary volume to Appletons' cyclopaedia of applied mechanics (1892)
Benjamin, Park, 1849-1922 · New York, D. Appleton · leaf 567
ld magnet and armature of the motor.The magnet, which consists of a single piece, is wound with wire connected to the two ter-minal brushes shown. This magnet is permanently fixed to the hub through which theshaft passes. The armature, shown in perspective in Fig. 10, is of the Gramme type, and… … Fig. 8.
Mechanical engineering
Internet Archive · Boston Library Consortium · Public Domain Mark 1.0. Free to use for anything.
