Modern mechanism, exhibiting the latest progress in machines, motors, and the transmission of power, being a supplementary volume to Appletons' cyclopaedia of applied mechanics (1892)
Benjamin, Park, 1849-1922 · New York, D. Appleton · leaf 574
Pig. 33.—Spiague armature. … Fig. 34.—Edeerton motor. Pig. 35.—Edgerton motor. Section. central prism of the same number of sides. Through the central axis of this prism, theshaft is placed longitudinally, and. as before stated, supported in bearings in the end capsof the motor. The outer or peripheral extremity of each of…
Mechanical engineering
