e, and ranges from2,100 revolutions per minute in the\ and ^ horse-power motors, to aslow as 360 in the 150 horse-povrermachine. Fio. 39.—Edison standard motor. Fig. 40 gives a view of the . . Standard Crocker- Wheeler motor. The machine is of the inverted horseshoe type ; each pole piece is… … AUTOMATICSTARTINGRHEOSTAT MOTOBS, ELECTRIC. 551 support for the bearings. The armature is relatively of very large diameter, and, comparedto the field, quite powerful. The armature is a Pacinotti ring with a comparatively smallamount of wire wound upon it. The clearance of the armature is so small…
