Fiii. 4. -Mowing inachine. Wide-cut adjustment. until a swath 5 ft.. 6 ft., and even wider, is the rule. This change has involved the intro-duction of a long finger bar, and the spring lift is a remedy for the difficulty found by the … Fig. 5.—Emerson, Talcott & Co.s mower. operator in raising the long bar, with its increased weight and adverse leverage against thegag-iron universally used in some form at the inner end of the bar to facilitate high lift ofthe outer end. To make this mower available with long or short finger…
