hemain pulley of the instrument,which is fixed to the front of thetable. This pulley is loose on aspindle which carries the cen-tring drum that supports one endof the record cylinder. A simi-lar drum, opposite the former,and at a distance from it corre-sponding to the length of thecylinder, nins… … Fig. 1.—Tlie phonograph.
