ipe by a rightand left screw, whichadjusts the pipe to thecentre of die; also stead-ies it when being cut off.Tlie cuttiiig-off arrange-ment is provided with aratchet and pawl, and ashort lever which pro-jects through an openingin the gear, and twice ineach revolution comes incontact with a… … Fig. 5.—Pipe-cutting and threading machine.
