started and stopped by a binding lever.A development of this machine, of much heavier build, for i)laning-mills, bridge work, etc.,has a stationary cylinder so tliat the countershaft may be either on the floor or overhead, asdesired. There is a chip-breaker for holding the fibre of the wood during… … -JSB^SS Fig. 5.—Endless-bed eiirface planer. allows the rollers to adjust to the different thicknesses of the lumber without unduly strain-ing any of the parts of the machine. The machine shown in Fig. 5 has the line of the bed in a fixeil position, the upper andthe lower cylinders, and the…
