aiid-si(!(> is discarded in this plow in favor of inclinedfurrow wheels. The implement is constructed of malleable iron and steel. The inclinedfurrow wheels perform the function of the land-side, besides carrying weight. With thelong lever the plow-point can be diverted ujnvard to run out of… … Fu.. 5.-IIill;^ide plo\.. given depth. A stiff rod connects two arras, one on each furrow-wheel spindle, causing themto track by steering the rear in unison with the front wheel as the horses direct the latter bythe swing of the tongue. Deeres Gilpin Sulky-Plow has a self-lifting device, introduced…
