are always kept in place by tlie guides. The Detroit Sure-Grip Tackle-Block is shown in Fig. .3. The brake which will hold theload at any point is sim[ily a wedge that drops by gravity between the upper sheaves. Thefjice of the wedge is fluted to the curve of the rope. The block is made of steel.…
