; but the cutaway machine, withthe same number of disks and depth of work, has less than 8 ft. of incisory bearing ; thisdiminishes the draft, and yet the disks, by their troweling action, chop the soil into finer frag-ments. In the Clark cutaway pulverizer, six shovel-blades enter the earth at… … Fig. 2.—Cutaway disk. PULVERIZERS AND HARROWS. 677 All harrows of the rotating-disk class are subject to a considerable amount of side pres-sure on each disk, which accumulates at the rearward hanger, causing a severe friction there.For this hanger, the Keystone Manufacturing Co., of Sterling.…
