ns, and the actual weight of coal consumed was charged upwithout deductions of any kind. This engine raised 12,000,000 gallons 150 ft. high in 24hours. Reynolds Screw Pumping-engine.—One of the most novel forms of pumping-engine thathave been built in recent years is that shown in Fig. 6, designed… … Flo. 5.—The Allis compound pumping-engine. PUMPS, RECIPROCATmG. 687 cast-iron circular housing or casing set in the brick walls of the tunnel. The wheel is keyedto the crank shaft of the Reynolds vertical compound condensing engine. Bearings forsupporting the outer end of the shaft are formed in…
