with a car-riage which IS pro-vided with a pin- ■ , ,ion and crank. The operator by turning the crank moves the dril 1 to any point along the bar.In quarries and in stone-yards it is frequentiv noticed that a number of men arc employedto drill small holes, from 3 to 6 in. deep, in large blocks, for… … Fig. 7.—Plug-and-feafher bar. Vertical.
