Modern mechanism, exhibiting the latest progress in machines, motors, and the transmission of power, being a supplementary volume to Appletons' cyclopaedia of applied mechanics (1892)
Benjamin, Park, 1849-1922 · New York, D. Appleton · leaf 756
Short gearluss motor. The spring connections for easy starting are shown in the ciit. … Fig. 19.—Field electric locomotive. A double arm, running outfrom the frame-work to the cross-girders of the truckmakes piovisionfor supporting theentire motor. A36-iLi. wheel is gen-erally employed,giving a clearanceof 5\ in. over thetrack. At a speedof 10 miles perhour, the armaturedrives a…
Mechanical engineering
Internet Archive · Boston Library Consortium · Public Domain Mark 1.0. Free to use for anything.
