60 lbs. the valve closes, and the pressure, passing from thetop to the bottom of the piston, puts the piston in equilibrium, andallows the weight, slowly settling d:wn, to open the damper, thuscontrolling the pressure at the desired limit. II. Pressure Regulators.—The Foster Pressure-regulating… … Fig. 3.—Kellams damper regulator. 3. -Curtis damperregulator. follows of valve, D, whichspindle, P. to the right to diminish the pressure, or theleft to increase tiie pressure. The delivery pressure, en-tering chamber, K, tends to raise the diaphragm, 11, anddraw valve, D, toward its seat ; in…
