Modern mechanism, exhibiting the latest progress in machines, motors, and the transmission of power, being a supplementary volume to Appletons' cyclopaedia of applied mechanics (1892)
Benjamin, Park, 1849-1922 · New York, D. Appleton · leaf 772
FiG. 3.—The Sellers bending rolls. ened. Indexes are provided for setting these rolls. The outer rolls of this series areadjustable independently ; the inner rolls are raised or lowered together, and the entire four … air ^traiiihteninji machine. rolls are also arranged so that, after being once set, they may all be adjusted at the sametime without disturbing their relative positions. 744 ROLLS, METAL WORKING. ROLLS, METAL WORKING. Roughing Train and Boubling 3Iachine for a Tin-plateRolling Mill. — Theodore L.…
Mechanical engineering
