Modern mechanism, exhibiting the latest progress in machines, motors, and the transmission of power, being a supplementary volume to Appletons' cyclopaedia of applied mechanics (1892)
Benjamin, Park, 1849-1922 · New York, D. Appleton · leaf 775
two upright rolls are used. One roll operates upon theinside of the ingot, as shown above, while the other roll operates on the outside. Theoutside roll is driven. It has a sharply beveled edge as a top cutter, a projecting flangeas a central cutter, and a bottom flange to support the base of the… … Fig. 5.—Ingot a.* cast.
Mechanical engineering
Internet Archive · Boston Library Consortium · Public Domain Mark 1.0. Free to use for anything.
