Singer chain-stitch machine. II. Machines FOR Manufacturing Purposes and Heavy Work.— The Wheeler & WilsonNo. 13 Machine, Fig. 10.—In this machine the moving power is applied to the upper revolv-ing shaft, which communicates a uniform rotary motion to the lower main shaft by meansof two… … F/G. 10.—Wheeler & Wilson heavy work uiacliiiiu. loop of upper thread. It moves in a circular guide with a motion alternately acceleratedand retarded. It is rotated by means of a driver attached to a short shaft, the axis of whichis eccentric to that of the main lower shaft, and which in…
