Fig. 2.—Refining kettle. 804 SOAP-MAKERS MACHINERY. weighing from 3 to 4 lbs. It has a single-acting steam cylinder placed underneath the bed … Fig. 3.—SoHp frame. in such position that its piston, by moans of a roller attached to the end of the piston rod, acts upon a cam surface of the swing orpendulum lever, as indicated. A hook,attached to the piston rod. engages with astud on tlie swing or pendi^lum levi-r andprevents the latter from…
