Fig. 30.—Train telegraph system. TELEGRAPH. 849 … Fig 31 —Plu Ip^ ind u ti )ii also to the diagram. Fig. 30, the general arrangement of the sending and receiving stations will Ije seen, that to the right representing the moving car. Taking the terminal station first, we find its principal equipment to consist simply of a main battery, a…
