Modern mechanism, exhibiting the latest progress in machines, motors, and the transmission of power, being a supplementary volume to Appletons' cyclopaedia of applied mechanics (1892)
Benjamin, Park, 1849-1922 · New York, D. Appleton · leaf 885
Fig. 2.—Gap-tenoninp; machine of cutter used, whicii completes the double tenon. There is a special attachmont, independ-ent of the tenoning part of the machine, for cutting gains, of)erating upon the underside of the timber,which is placed on the carriage and passed over the heati There isused an… … Fig. 3.—The Rogers tenouin machine. the machine. When it is used as a gaining machine, it is worked from the back ; when usedas a tenoning machine, from the front ; when it is being used as a gaining machine, thetenoning part is made idle simply by casting off the belt ; and the same way with…
Mechanical engineering
Internet Archive · Boston Library Consortium · Public Domain Mark 1.0. Free to use for anything.
