bs of any shape or size, at one operation. The table is builtin two parts. The lower half is gibbed and fitted to the frame in V-shaped ways, withadjustment horizontally in line with the mandrel, by hand wheel and screw, to center theknives with the hub block. The upper table, with roughing and… … ilG. •^.—Automatic liub-tuniiug macliiiie. the finishing knives to the hub block. The roughing knife, with a straight face 18 in.long, is held in a stand at the back of the sliding carriage, with its cutting edge extendingdownward, and when working takes off surplus material from the hub block in…
