holes,punched 4 to 8 in. diameter, at one time, andthe range of speed is such as to adapt the ma-chine for drilling down to U-in. holes. Thetwo columns have both power and hand move-ment for adjustment on the bed. The headsliave 18 in. reach, boring to the center of 36 in.They will take in under… … Fig. 7.—Brown & Sharpes chucking-machine.
