ame, of a bevel gearing,whose pinion is keyed to thewinch shaft, and of a pair ofhelicoidal gearings. Upon theshaft that connects the twobevel wheels is keyed a drum, provided with depressions for the reception of the chain towhich the load to be lilted is attached. The endless screw has several… … Fig. 2.—Eavelli windlass. 916 WIRE STRAIGHTENING. Upon the whole, this endless screw constitutes a sort of a disk.iipon the circumference of whichare arranged a variable number of pins that are slightly inclined with respect to the bases ofthe disk. At every fraction of a revolution correspondinj;…
