Fig. 24 30 THE UP-TO-DATE the dotted lines show the manner in which each piecemust be rebated. After rebating, cut the pins, thenmark the dovetails and chop them out, atter whichproceed to miter the laps on both pieces and cut the Mttre Dovetailing … Fig. 25 Fig. 26 miter across the edge, and, if neatly done, the jointwill go together at the first trial. Bevel or splay dovetailing is much more difficultthan any of the preceding, and is not so generallyknown. The required bevel being given, proceed asfollows: First joint the ends to the required…
