Modern practice of the electric telegraph : a handbook for electricians and operators (1874)
Pope, Frank L., 1840-1895 · New York : D. Van Nostrand · leaf 45
ents are also made in seve-ral other forms, and various devices for increasing thesound of the lever arc made use of. On many linesthey are found to answer as well as the usual arrange-ment, employing a relay and local battery. * The instrument shown in the figure is from the manufactory of C. T.… … Fig. 16. 58. Arrangement of a Terminal Station.—Fig. 17is a diagram showing the arrangement of wires, batteries,
Telegraph
Internet Archive · Public Domain Mark 1.0. Free to use for anything.
