ENGINE PARTS 33 flowing through the tubing, and the disks ab¬ sorbing its heat and giving it up to the air, but these are being abandoned in favor of Fig. 15. — Radiator Constructions. A, Spiral flange (water passes through the tube) ; B, cellular, and C, honeycomb (air passes through the tubes;… … The heated water enters Fig. 16.— Radiator at the top of the case in AND Fan' which the tubes are contained, and flows to the bottom, finding passages between the tubes,
