The mysteryes of nature and art : conteined in foure severall tretises, the first of water workes, the second of fyer workes, the third of drawing, colouring, painting, and engrauing, the fourth of divers experiments, as wel serviceable as delightful (1634)

Bate, John · Imprinted at London : For Ralph Mab and are to be sold by Iohn Iackson and Francis Church at the Kings armes in Cheapeside · leaf 27

An illustration from The mysteryes of nature and art : conteined in foure severall tretises, the first of water workes, the second of fyer workes, the third of drawing, colouring, painting, and engrauing, the fourth of divers experiments, as wel serviceable as delightful, 1634, leaf 27
hrough the holes of the brirame, fcrcw it faft untothe top of the table. Note that the table mufi bee leathe-red alfo underneath the compaffcof the brimme of thelower brade. Now the lowermoft braffe muft be of equaldiameter (in hollownefle) unto the other, but it muft bemorcfpirall towards the… … holes in the tablc,on each fide of chcbrafle onc,anfwcra-blc unto the holes of the brim of the lower braiTc> throghwhich holes put the two rods, of the yron hanged untothe fweepe through them, and riuet them flrongly intothe holes ofthe lower braffe. Place this in water, and bymouing the fweepe…

Hydraulic machinery · Fireworks · Art -- Technique · Workshop recipes
