Research on low density thermal insulation materials for use above 3000 deg f sixth quarterly status report, 1 jul.-30 sep. 1963 (1963)

Styhr, K. H · leaf 24

An illustration from Research on low density thermal insulation materials for use above 3000 deg f sixth quarterly status report, 1 jul.-30 sep. 1963, 1963, leaf 24 — PONER CABLE /^ 10 V 250 A WATER COOLED STEEL SHELL GRAPHITE HELIX MOLYBDENUM SIGHT TUBES TERMINAL AS ABOVE BCBBLED ZIRCONIA INSULATION DENSE CERAMIC SPECIMEN AND GUARD RINGS FOAMED ZIRCONIA INSULATION FIGURE 2

Barriers · Ceramics · Radiative heat transfer · Refractory materials · Thermal insulation · High temperature · Insulation · Low density materials · Refractories

Internet Archive · NASA Technical Reports · Public domain (US government work). Free to use for anything.
