Research on low density thermal insulation materials for use above 3000 deg f sixth quarterly status report, 1 jul.-30 sep. 1963 (1963)

Styhr, K. H · leaf 26

An illustration from Research on low density thermal insulation materials for use above 3000 deg f sixth quarterly status report, 1 jul.-30 sep. 1963, 1963, leaf 26
L WATER COOLED POWER TERMINALS, 1 VOLT STEPS TO 25V UP TO 400 AMPS MOLYBDENUM RADIATION SHIELDS NICKEL OR STAINLESS STEEL WATER COOLED STEEL SHELL THERMOCOUPLE WELLS (6 AT 90° TO SIGHT TUBES) BUBBLED ZIRCONIA INSULATION DENSE CERAMIC SPECIMEN AND GUARD RINGS FOAMED ZIRCONIA INSULATION

Barriers · Ceramics · Radiative heat transfer · Refractory materials · Thermal insulation · High temperature · Insulation · Low density materials · Refractories
