Large spacecraft antennas - New geometric configuration design concepts (1971)

Oliver, R. E · leaf 2

An illustration from Large spacecraft antennas - New geometric configuration design concepts, 1971, leaf 2
Figure 1. Modified Cassegrain feed paraboloidai antenna MAIN REFLECTOR AXIS OF ELLIPSE OF PARABOLA SUBREFLECTOR FEED—^ ^—ANTENNA AXIS Figure 2. !\^odified Cassegrain with ellipse-generated subreflector arc C-E of a hyperbola, the major axis of which passes through F and B. The subreflector thus…
